FTTH Drop Cable Production: How the Manufacturing Process Works
Did you know: more than 70% of U.S. broadband rollouts now use fiber networks that need high-precision manufacturing to hit performance targets.
Shanghai Weiye OFC Equipment handles complete fiber secondary coating line manufacturing, from selecting brand fibers like Fujikura or Corning® SMF-28e to complete test reports that guarantee full quality assurance.
Our FTTH drop designs suit aerial, ducted, and direct burial installation, with low-smoke zero-halogen (LSZH), PVC, and polyethylene (PE) jacket options and arrangements from 1–4 cores. We provide single-mode OS1/OS2 and multimode OM2–OM4 grades plus G.652D and G.657 variants, Pantone sheath colors, and custom logo printing.
Automation and precision equipment keep line speed steady and maximize repeatability. Typical lead times run 4–5 days for orders under 100 km and 7–10 days for < 500 km, with an MOQ of 1 km and free-replacement warranty for quality problems.
Read on to learn how materials plus testing and support combine to lower lifecycle cost and match the right product to your network system.
- Shanghai Weiye OFC Equipment offers full manufacturing with lab validation for U.S. deployments.
- Multiple jacket choices and fiber grades support different install environments.
- Automated production lines deliver consistent quality and stable optical performance.
- Fast lead times, low MOQ, and brand fiber options support reliable procurement planning.
- Comprehensive test reports and after-sales warranty back product reliability and compliance documentation needs.
Expert FTTH manufacturing by Shanghai Weiye OFC Equipment
When schedules and performance count, Shanghai Weiye OFC Equipment delivers customized drop cables with complete test documentation.
As a focused supplier and manufacturer, Shanghai Weiye OFC Equipment pairs purpose-built equipment with tight material control. We provide custom builds and services for residential/MDU deployments. Every order comes with 100% quality assurance and complete test reports.
Our lab conducts high-temperature, salt spray, and vibration tests to verify durability. Jacket options include LSZH, PVC, and PE. Designs cover flat bow-type and self-supporting styles and support brand fibers such as Fujikura® and Corning SMF-28e.
- Documented line control and production checks for shipments with audit trails.
- Engineering support for requirements, pilots, and scaling.
- Modern fixturing and calibration minimize variation so every cable meets operator standards.
How We Produce FTTH Cable
At Shanghai Weiye OFC Equipment, manufacturing steps are built around network requirements, pairing brand fiber choices with strict test routines.
Optical fiber selection and brand options
We align fiber secondary coating line to minimum bend radius, loss, and deployment type. Options include OS1, OS2, OM2–OM4 and ITU-T G.652D, G.657.A1/A2. Brand fibers such as Fujikura and Corning SMF-28e are available to meet procurement standards.
Integrating Strength Members
Strength members use dielectric FRP or galvanized steel wire. FRP is ideal where non-conductive runs are required. Steel wire adds tensile strength for longer aerial spans and bonding/grounding needs.
Jacket extrusion and process control
Jacket options include LSZH for flame/smoke safety, PVC for flexibility and ease of handling, and PE for outdoor UV and moisture resistance. Closed-loop control of extruder temperature and capstan speed stabilizes line speed and critical dimensions.
| Member | Dielectric FRP | Metallic Steel |
|---|---|---|
| Primary use | Non-conductive runs | High-tension aerial runs |
| Advantage | Light, non-corrosive | Very high tensile strength |
| Installation note | Easier terminations | Bonding/grounding required |
Testing & Verification
Inline geometry/concentricity checks operate in-line. Final optical tests confirm loss and reflectance. Each order ships with a 100% test report and lab results from high heat, salt fog, and vibration trials to confirm handling for drop terminations and field use.
Typical lead times are under 100 km in 4–5 days and under 500 km in 7–10 days. Material lot records and first-article approvals support traceability and compliance for U.S. programs.
Our FTTH Drop Cable Types and Structures
Shanghai Weiye OFC Equipment provides a compact portfolio of FTTH drop designs that fit indoor risers and long aerial runs. Each option pairs tested materials with geometry tuned for field termination and stable optical performance.
The bow-type flat drop cable minimizes footprint for risers/ducts. It reduces bend loss for simple routing in hallways and MDUs.
Self-supporting designs for aerial spans
Self-supporting FTTH drop designs use a messenger element to carry tensile loads. Choose FRP (dielectric) for electrical isolation or steel messenger when bonding and higher tensile strength are required.
Strength member and core layouts
We provide dielectric and metallic strength member configurations to meet safety/EMI requirements. Center loose tube and flat unitube types balance crush resistance and fiber secondary coating line for fast terminations.
Indoor vs Outdoor Jackets
Jacket choices include LSZH for indoor flame/smoke compliance and PE for outdoor UV and moisture resilience. Each series is qualified for mechanical and optical quality before shipment.
| Type | Best use | Strength element | Jacket |
|---|---|---|---|
| Bow-type flat | Indoor risers and MDUs | Dielectric FRP | LSZH |
| Self-supporting | Overhead spans | FRP/Steel | PE |
| Central loose-tube | Higher fiber counts | FRP | LSZH or PE |
| Unitube flat | Low-count, easy strip | FRP/Steel | LSZH/PE |
Equipment Ensuring Quality and Throughput
Automation and sensor-driven feedback at Shanghai Weiye OFC Equipment cut manual handling and increase throughput for drop patch preparation.
Our production line integrates automated machines that cut/strip drop cords to raise throughput and reduce operator variability.
The CLX-BPO2 auto-stripping machine uses PLC + photoelectric control. One cycle is ~1.5 s, giving real-world speeds near 20 terminal operations per minute.
Automated Cut/Strip for Drop Cords
The equipment strips LSZH/PVC jackets and trims FRP/steel members to precise reserved lengths. Cylinder-driven actuators provide quick, repeatable motion and minimize downtime.
Closed-Loop Control for Repeatability
PLC logic and photoelectric sensors deliver precise positioning and feedback control. Inline checks feed control charts so operators can adjust drifts before defects grow.
| Feature | Capability | Benefit |
|---|---|---|
| CLX-BPO2 | 1.5s cycle, auto-strip | ~20 terminals/minute throughput |
| Drive | Cylinder-based | High speed and reliability |
| Material handling | LSZH & PVC; FRP & steel | Accurate stubs, clean terminations |
| Control | PLC/photoelectric with in-line SPC | Stable quality, reduced rework |
- Auto scrap ejection and ergonomic feeders keep the line clean.
- PCPs document calibration and key parameters.
- Combined machines, fixtures, and trained staff help meet FTTH volume goals without sacrificing accuracy.
What the CLX-BPO2 Adds
The CLX-BPO2 brings industrial-grade stripping and trimming to our line, cutting cycle time while keeping prep consistent.
Shanghai Weiye OFC Equipment uses the CLX-BPO2 to increase throughput and standardize terminal quality. The unit cycles in ~1.5 seconds, producing around 20 preps per minute in production.
PLC and photoelectric control deliver exact detection and repeatable actuation. That control keeps strip and stub lengths within tight tolerances.
Cycle time and throughput
Typical operation speed is ~1.5 seconds per cycle. This converts to steady throughput under normal production conditions.
Supported Strip and Stub Lengths
The CLX-BPO2 handles LSZH/PVC with an adjustable jacket strip length from 17.5 to 35.0 mm. Reserved stubs are adjustable from 7.0–11.0 mm to fit common termination hardware.
Cutting FRP/Steel Members
The machine cleanly cuts FRP and steel wire strength elements while protecting adjacent fibers. Custom tooling are offered for nonstandard sizes to maintain precision.
- Auto-eject scrap and sensor start reduce idle time.
- Compact size (L40 × W18 × H18 cm), 110–220V, 50W, and 11 kg weight simplify cell integration.
- Pneumatic cylinders and PLC/photoelectric control boost reliability and reduce maintenance downtime.
| Spec | Value | Why it matters |
|---|---|---|
| Cycle | ~1.5 s (~20/min) | High throughput for production runs |
| Jacket strip (A) | 17.5 to 35.0 mm | Fits common connector processes |
| Stub (B) | 7.0 to 11.0 mm | Meets strength and termination needs |
| Power/Size | 110–220V, 50W; 40×18×18 cm | Easy integration into existing equipment |
Using this machine, Shanghai Weiye OFC Equipment standardizes terminal prep so field teams get drop parts install-ready. The CLX-BPO2 supports our lines in meeting volume targets without compromising quality.
Tailored Specifications for Your Network
Shanghai Weiye OFC Equipment configures every order to meet your network requirements and simplify deployment. We combine focused options with predictable schedules so your teams get install-ready reels.
Choose 1 to 4 cores with single-mode or multimode fiber. Options include OS1, OS2, and OM2–OM4 along with G.652D and G.657 variants to align with optics and connector plans.
We match sheath colors to Pantone codes for fast field ID and consistent asset tagging.
Jacket materials, print legends, and branding
Select LSZH/PVC/PE jackets to suit route and safety requirements. Custom print legends and logos aid inventory/warranty tracking.
Put-Ups, Packaging, and Structures
Standard reel lengths are 1/2/4 km with custom reels and packaging to fit storage/handling. Choose flat bow-type or self-supporting and FRP or steel members to fit span and isolation requirements.
| Option | Common choice | Benefit |
|---|---|---|
| Reel length | 1 / 2 / 4 km | Less staging, easier reels |
| Sheath | LSZH, PE, PVC | Indoor/outdoor compatibility |
| Structure | Bow-type / Self-supporting | Flexible routing/span |
As a manufacturer, Shanghai Weiye aligns runs to your schedule and provides docs that lists final specifications for easy on-site QA.
QA, Testing & Documentation
Shanghai Weiye OFC Equipment builds checkpoints into production so every item has recorded acceptance data at ship.
Environmental and Mechanical Tests
Our lab runs elevated-temperature exposure, salt fog corrosion, and vibration tests to qualify materials/assemblies. These tests recreate field stresses for indoor and outdoor use.
Full Test Reports for Every Reel
Every fiber optic cable ships with a 100% test report that records loss, return loss, and key geometry where applicable. Final inspection gates stop nonconforming items before they leave the factory.
Traceability and compliance
Batch records tie test data to reels and serials so audits and warranty claims are simple to verify. Documentation uses standard customer templates to speed approvals and inbound inspection.
- In-line checks plus final inspection reduce field failures and cut warranty events.
- Quality packages include specifications confirmation and formatted data for quick review.
- Continuous test trends inform preventive maintenance and raise long-term reliability.
| Test | Purpose | Result |
|---|---|---|
| High-temperature | Material stability | Validated heat endurance |
| Salt-fog | Corrosion resistance | Qualified for outdoor use |
| Vibration | Resistance to vibration | Reduced field failures |
FTTH Drop Cable Pricing & Cost Drivers
Budget planning for a drop starts with fiber and jacket choices and is shaped by volume and customization.
Typical prices range broadly—from about $30 to $1,000 per unit—based on fiber grade (G.652/G.657/OM2–OM4), jacket chemistry (LSZH, PVC, PE), length, and design structure.
Primary Cost Inputs
The primary cost drivers are fiber grade, jacket material, and the structural type chosen for deployment.
Self-supporting designs and steel strength elements increase material/labor. Custom colors, logos, and print legends add setup and influence price for short runs.
Length/Volume/Customization Impact
Longer put-ups and larger volumes reduce unit cost. Short runs often carry setup fees and higher unit prices.
- Line changeovers and custom tooling extend lead time and add cost.
- Clear RFQs with schedule alignment let Shanghai Weiye OFC Equipment align price quotes to delivery windows.
- Framework agreements and indexed pricing stabilize budgets over phases.
| Driver | Effect on price | Guidance |
|---|---|---|
| Fiber grade | Large | Right-size spec to budget |
| Jacket type | Medium impact | Compare LSZH vs. PE for total cost |
| Order length / volume | High impact | Consolidate runs to cut unit cost |
Logistics for the U.S.
Shanghai Weiye OFC Equipment keeps lead times/logistics clear so planners can align staffing and sites. Predictable schedules cut downtime and help control cost when a rollout is underway.
Production Windows & Capacity
Typical production windows run 4–5 days for orders under 100 km and 7–10 days for < 500 km. We plan capacity to track your milestones and to maintain on-time delivery.
The service team provides updates/tracking so installation teams can plan arrivals. For compressed schedules, we reserve contingency capacity to accelerate critical-path orders.
MOQ and Rationale
The MOQ is 1 km. This reflects line setup such as wire and jacket die adjustments that consume start-up material and scrap.
We review your put-ups and staging to choose reel sizes that cut waste and handling. Staggered batches can balance inventory holding with more frequent small-site deliveries.
Installation Scenarios & Readiness
Site conditions determine whether a self-supporting span, ducted pull, or direct-buried run is the best fit for a project.
Deployment Considerations
For aerial runs, Shanghai Weiye OFC Equipment recommends self-supporting designs with correct strength members to manage sag/tension for long-term stability.
Duct installations work best with low-friction sheaths and crush-resistant constructs so pulling avoids fiber damage. PE jackets are typical for underground and buried paths where moisture resistance matters.
Direct-buried designs require proper depth control per local codes and moisture barriers to protect the optic core over time.
Indoor Riser/Plenum & ONT
Indoor riser and plenum routes prefer LSZH to meet flame and smoke rules. Flat drop cable forms strip cleanly and present controlled strength stubs for fast ONT terminations.
We guide the choice of steel or FRP (dielectric) strength members based on bonding needs, lightning risk, and hardware fit. Standardized line prep reduces install time and minimizes scrap.
| Scenario | Key feature | Installer note |
|---|---|---|
| Aerial | Self-supporting (steel/FRP) | Check tension and messenger hardware |
| Duct | Low-friction jacket, crush resistance | Use pull tape + lubricant |
| Direct burial | PE jacket, moisture barrier | Follow local depth and warning tape rules |
| Indoor | LSZH jacket, tight bend support | Maintain bend radius at penetrations |
Our approach ensures a consistent install experience across indoor outdoor transitions. That leads to fewer callbacks, speeds activations, and stable field performance for your system.
Support from Spec to Service
Our team coordinates tests, line schedules, and installation guidance to remove surprises during deployment.
Shanghai Weiye OFC Equipment provides engineering support from early requirements through approved drawings and pilot builds. We deliver documentation templates and clear installation notes so field crews work from the same plan.
After-sales service includes fast response, RCA, and corrective action. All products ship with full test reports and traceability to help QA acceptance.
- 24/7 availability for status updates and technical guidance.
- Warranty with free replacement if any quality problems are confirmed.
- Coordination of line schedules for expedites and urgent changes.
- Configuration control so shipped items match agreed requirements every time.
| Support area | Scope | Benefit |
|---|---|---|
| Engineering | Spec review & pre-production builds | Fewer field issues |
| Testing | Lab + 100% reports | Full traceability |
| After-sales | Rapid replacement & root-cause | Lower downtime |
Conclusion
Choose Shanghai Weiye OFC Equipment for tailored drop builds, short lead times, and traceable quality records.
We deliver customized FTTH drop solutions that combine materials with validated manufacturing and lab tests. Every reel ships with a 100% test report and documented lab trials to support field acceptance in the United States.
A robust production line, including CLX-BPO2-enabled prep machines, reduces variability and shortens turnaround. Our equipment set standardize strip/stub lengths so installers see consistent results at turn-up.
From fiber selection to jacket, printing, and packaging, we balance design and cost to maximize service life. Dedicated customer support guides scheduling, logistics, and after-sales care so your deployment remains on plan.
Contact Shanghai Weiye OFC Equipment to align specs, timeline, and volume. We stand behind every shipment with lab validation and responsive support.
